Description
Gas Detection & Warning System TSPCS-02
Main Applications:
lPetrochemical Refineries: For monitoring and safety in oil refining facilities.
lChemical Industry Parks: To ensure safety and early detection in chemical production areas.
lHazardous Chemicals Parking Lots: For detecting dangerous gases in areas where hazardous chemicals are stored.
lOil and Gas Pipelines: To monitor and detect gas leaks along pipeline routes.
lOil and Gas Terminals: Ensuring safety and early warning at terminals where oil and gas are handled.
lOil and Gas Storage Tanks: For detecting leaks or hazardous gas presence around storage tanks.
Size
580 × 500 × 700mm
Specifications
Visible Light, Infrared, Laser, Pan-Tilt
Performance Parameters
Resolution: Visible Light: 1920×1080; Infrared: 640×512
Infrared Spectral Range: 7.5μm~10.5μm, supports up to 10 spectral channels
Monitoring Distance: ≥ 3 km
NETD (Noise Equivalent Temp. Difference): ≤ 25 mK
Field of View: Visible Light: 1° ~ 30°;
Infrared: 2.7° ~ 7.3°
Alarm Response Time: ≤ 2 s
Pan/Tilt Speed: 0.01°/s ~ 60°/s
Pan/Tilt Angles: Horizontal: 360°; – Tilt: -25° ~ +45°
Inspection Modes: Supports point inspection, sector inspection, and alert detection modes
Operating System: Windows 7/10
Software: Hazardous Gas Detection System Software
Operating Temperature: -35°C ~ +65°C
Storage Temperature: -40°C ~ +70°C
Protection Rating: IP66
